JG-10060SG / JG-13090SG

Laser Cutting and Engraving Machine for Nonmetal

The electric lifting worktable can intelligently adjust the height of the worktable for materials of different thicknesses.

Especially suitable for advertising and crafts industries, processing of different thickness materials such as wood, acrylic, veneer and EVA.

Zinc-iron alloy honeycomb worktable and knife strip panel worktable can be selected according to processing requirements.

Technical specifications of the laser cutting engraving machine

Model No.

JG-10060SG

JG-13090SG

Working area

1000mm×600mm (39.3”×23.6”)

1300mm×900mm (51.1”×35.4”)

Working table

Zinc-iron alloy honeycomb worktable / Knife strip panel worktable (Electric lifting)

Laser type

CO2 DC glass laser tube

Laser power

80 watt ~ 150 watt

Motion system

Step motor

Working accuracy

±0.1mm

Cooling system

Constant temperature water chiller

Supported graphics formats

PLT, DXF, AI, BMP, DST, etc.

Power supply

AC220V±5%  50 / 60Hz



Product Application
